Description
| Standards and Protocols | IEEE 802.3i/802.3u/ 802.3ab/802.3x, IEEE 802.1p |
|---|---|
| Interface | 8 10/100/1000Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports |
| Fan Quantity | Fanless |
| External Power Supply | External Power Adapter (Output: 9VDC / 0.6A) |
| LED | System Power Link/Act indicators per port built into each RJ-45 port |
| Dimensions ( W x D x H ) | 6.2 x 3.9 x 1.0 in. (158 x 99.1x 25 mm) |
| Max. Power Consumption | 3.7W(220V/50Hz) |
| Max. Heat Dissipation | 12.617 Btu/hr |
| Packet Forwarding Rate | 11.9 Mpps |
|---|---|
| MAC Address Table | 4K |
| Packet Buffer Memory | 1.5 Mb |
| Jumbo Frame | 16 KB |
| Advanced Features | Green Technology 802.3X Flow Control 802.1P/DSCP QoS |
|---|---|
| Transmission Method | Store and Forward |
| Certification | CE, FCC, RoHS |
|---|---|
| Package Content | 8-Port 10/100/1000Mbps Desktop Switch Power Adapter Installation Guide |
| Environment | Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5%~90% non-condensing |
