Description
| Hardware | |
| Interface | – 1 *10/100Mbps Ethernet port |
| Power Supply | – AC 100V~240V |
| Button | – 1 *5GHz WPS , 1*2.4GHz WPS, 1 *Power ON/OFF Slide Switch, 1*RST |
| LEDÂ Indicators | – 4*2.4G, 4* 5G, 1 *Power, 1 *CPU, 1 *5G EXT, 1*2.4G EXT, 1*LAN |
| Antenna | – 2 *5dBi External Antennas |
| Dimensions (L x W x H) | – 117 x 72 x 66mm (not including antennas) |
|
Wireless |
|
| Standards | – IEEE802.11ac,
– IEEE 802.11a, – IEEE 802.11n, – IEEE 802.11g, – IEEE 802.11b |
| RF Frequency | – 2.4GHz/5GHz |
| Data Rate | – 2.4GHz: 300Mbps
– 5GHz: 867Mbps |
| EIRP | – 2.4GHz < 20dBm
– 5GHz < 20dBm |
| Reception Sensitivity | – 2.4GHz：
11b 11M：-81dBm @ 8ï¼…PER 11g 54M：-68dBm @ 10ï¼…PER 11n HT20 MCS7：-65dBm @ 10ï¼…PER 11n HT40 MCS7：-62dBm @ 10ï¼…PER – 5GHz： 11a 54M：-68dBm @ 10ï¼…PER 11n HT20 MCS7：-65dBm @ 10ï¼…PER 11n HT40 MCS7：-62dBm @ 10ï¼…PER 11ac VHT80 MCS9：-51dBm @ 10ï¼…PER |
| Advanced Features | – Easy Wi-Fi Extension by Smart Phone
– TOTOLINK APP |
| Others |
|
| Package Contents | – EX1200M Wireless Extender *1
– Ethernet Cable *1 – Quick Installation Guide *1 |
| Environment | – Operating Temperature: 0℃~50 ℃ (32 ℉~122℉)
– Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) – Operating Humidity: 5%~95% non-condensing – Storage Humidity: 5%~95% non-condensing |
