Description
| PERFORMANCE | |
| Processor |
Intel® Core i7-14700, 20C (8P + 12E) / 28T, Max Turbo up to 5.4GHz, P-core 2.1 / 5.3GHz, E-core 1.5 / 4.2GHz, 33MB Intel Smart Cache
|
| Graphics |
Integrated Intel® UHD Graphics 770
|
| Chipset |
Intel® Q670 Chipset
|
| Memory |
1x 16GB UDIMM DDR5-5600
|
| Memory Slots |
Two DDR5 UDIMM slots, dual-channel capable
|
| Max Memory |
Up to 64GB DDR5
|
| Storage |
512GB SSD M.2 2280 PCIe® 4.0×4 NVMe® Opal 2.0
|
| Max Storage Support |
Up to three drives, 1x 3.5″ HDD + 1x 2.5″ HDD + 1x M.2 SSD • 3.5″ HDD up to 2TB • 2.5″ HDD bay is only for customer self upgrade • M.2 SSD up to 2TB each
|
| Card Reader |
3-in-1 Card Reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC623-CG codec
|
| Speakers |
1Wx1
|
| Power Supply |
260W 90%
|
| DESIGN | |
| Keyboard |
USB Calliope Keyboard, Black, English
|
| Mouse |
USB Calliope Mouse, Black
|
| Optional Bay |
Optional 2.5″ Bay
|
| Expansion Slots |
|
| Case Color |
Black
|
| Stand |
None
|
| Dust Filter |
None
|
| Pen |
Pen Not Supported
|
| Form Factor |
SFF (8.2L)
|
| Dimensions (WxDxH) |
92.5 x 297.7 x 339.5 mm (3.6 x 11.7 x 13.4 inches)
|
| Weight |
Around 5.3 kg (11.7 lbs)
|
| CONNECTIVITY | |
| WLAN + Bluetooth |
Intel® Wi-Fi® 6 AX201, 802.11ax 2×2 + BT5.2
|
| WWAN |
WWAN Not Supported
|
| Ethernet |
Integrated 100/1000M
|
| Front Ports |
|
| Optional Front Ports (configured) |
1x card reader
|
| Rear Ports |
|
| Optional Rear Ports (configured) |
None
|
| SECURITY & PRIVACY | |
| Security Chip |
Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
|
| Fingerprint Reader |
No fingerprint reader
|
| Physical Locks |
|
| Smart Cable Clip |
None
|
| Chassis E-Lock |
None
|
| Chassis Intrusion Switch |
None
|
| MANAGEABILITY | |
| System Management |
Non-vPro®
|
| SERVICE | |
| Base Warranty |
1-year, Onsite
|
| Included Upgrade |
3Y Premier Support Upgrade from 1Y Onsite
|
| CERTIFICATIONS | |
| Green Certifications |
|
| Mil-Spec Test |
MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Solar Radiation, Contamination by Fluids, Salt Fog)
|
| SOFTWARE | |
| Operating System |
Windows® 11 Pro, English
|
