Description
Camera
| Image Sensor | 1/2.7’’2MP HD progressive scan CMOS |
| Shutter Speed | Self-adaptive shutter |
| Lens | 2.8mm@F2.0, Horizontal angle: 115°, Diagonal angle: 135° |
| Lens Mount | M12 |
| Day & Night | IR-cut filter with auto-switching |
| DNR | 3D DNR |
| WDR | Digital WDR |
Compression
| Video Compression | H.264 |
| H.264 Type | Main profile |
| Video Bit Rate | HD, balanced and smooth bit rate |
| Max Resolution | 1920×1080 |
| Image Setting | Brightness, contrast, saturation, etc. (configurable via EZVIZ Studio) |
| BLC | Yes |
Network
| Storage | Support Micro SD card (Max. 128G) |
| Smart Alarm | Motion detection |
| Wi-Fi Pairing | SmartConfig (Wi-Fi One-Key Configuration)/AP paring |
| Protocol | EZVIZ cloud proprietary protocol |
| Interface Protocol | EZVIZ cloud proprietary protocol |
| General Features | Anti-Flicker, Dual-Stream, Heartbeat Messages, Mirror Image, Password Protection, Watermark |
| Minimum Network Requirements | 2Mbps |
Wi-Fi
| Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps |
General
| Operating Conditions | -10ºC ~ 50ºC (14°F ~ 122°F), Humidity 95% or less (non-condensing) |
| Power Supply | DC 5V±10% |
| Power Consumption | Max. 3W |
| IR Range | Max. 7.5 meters |
| Product Dimensions | 128mm x 58mm x 38mm |
| Packaging Dimensions | 149mm x 87.5mm x 91.5mm |
| Weight | 120g |
